Double Colors PVC Layflat Hose Extrusion Line
You are here: Home » Extruder machine » PVC Layflat hose machine » Double colors PVC layflat hose extrusion line » Double Colors PVC Layflat Hose Extrusion Line

Double Colors PVC Layflat Hose Extrusion Line

Double colors with 2 set extruders.
Yarn bobbins: 24+24 pcs with 12kg yarn bobbin.
60+60 with 3kg yarn bobbin.
Availability:
Quantity:
sharethis sharing button
  • SJ75-2

  • Jingda

  • 84778000

Application: It is widely used for auxiliary equipment in agriculture and forestry irrigation and is fit for converying liquid at low or medium temperature and under high pressure.

Working temperature: -5-65℃

Construction: Three layers, inner and outer layers are PVC, middle layer is polyester yarn. Inner layer and outer layer can be different colors or material.

Machine List:

Extruder

SJ75/30-2

SJ90/30-2

Bracket   for polyester yarn

One set (24*24   bobbins)

Die   head (mm)

1.1/2" - 3

4 - 8

Polyester   yarn knitting unit (Braider)

one set

Cooling   bath

one set

Haul-off   & Winding unit

one set



With convex plastic-coated surface of the hose , high burst pressure and long service life, it is wear resistant, attractive, soft, light, nontoxic, flavorless and environment protection.

Technical data sheet:



 W.P.

 B.P.

weight

Packing   size

Volume

        At 23

Inch

I.D   mm

Thickness   mm

m/Roll

BAR

BAR

KG/roll

D   x H cm

M3

3/4″

20

1.55

50

10.5

31.5

14

51x4

0.010

1″

26

1.7

50

10.5

31.5

20

53x5

0.014

1-1/4″

33

1.45

50

10.5

31.5

21

49x6

0.014

1-1/2″

41

1.9

50

10.5

31.5

29

51.5x7.5

0.020

1-3/4″

45

1.6

50

8

24

32

51.5x8

0.021

1-3/4″

45

2

50

10.5

31.5

35

53x8

0.022

2″

53

1.5

50

8

24

35

57x8

0.026

2″

53

2.05

50

10.5

31.5

42

57x9

0.029

2.5″

66

2.15

50

10.5

31.5

54

61x11.5

0.043

3″

78

2.25

50

9

27

66

62x13

0.050

3″

78

2.5

50

10

30

85

62x14

0.054

4″

104

2.55

50

9

27

100

63x18

0.071

6″

155

3

50

6

18

200

68x26

0.120

8″

207

2.95

50

5

15

220

63x34

0.135

8″

207

3.15

50

6

18

280

70x35

0.172
